AIHC-707G2/AIAB-707G2
1. Intel® LGA1200 Socket Supports 10th Gen CoreTM Processor(Max 100W）
2. Intel® Comet Lake‐S H410 Chip
3. Support 2*DDR4 2933/2666MHz, up to 64GB Dram
4. Realtek HD Audio
5. 1*Intel®i225V 2.5Giga LAN +1* Intel® i211AT Giga LAN
6. Support 4* SATA III
|
Form Factor
|
|
Dimensions
|
− ATX ( 305 * 220mm)
|
|
Processor System
|
|
CPU
|
− Intel®LGA1200 Socket
Supports 10th Gen CoreTM Processor Max 100W
|
|
Core Number
|
− by CPU
|
|
Max Speed
|
− by CPU
|
|
L2 Cache
|
− by CPU
|
|
Chipset
|
− H410
|
|
BIOS
|
− AMI 256M Flash ROM
|
|
Expansion Slot
|
|
M.2 M key
|
− 1*2242/2280，(SATA
Interface，CO‐lay SATA4)
|
|
SATA
|
− 4(SATA4 Co‐lay M.2)
|
|
PCI‐e
|
− 1*PCI‐E x16 + 1*PCI‐E x4
slot
|
|
PCI
|
− 5*PCI slots
|
|
Memory
|
|
Technology
|
− DDR4 2933/2666 MHz DRAM
|
|
Max.
|
− 64GB
|
|
Socket
|
− 2* LONG DIMM
|
|
Graphics
|
|
Controller
|
− Intel® HD Graphics
|
|
VRAM
|
− Shared Memory
|
|
VGA
|
− 1 (Max Resolution :
1920x1200@60Hz)
|
|
HDMI 1.4
|
− 1 (Max Resolution :
4096x2304@24Hz)
|
|
Multi
Display
|
− 2
|
|
Ethernet
|
|
Ethernet
|
‐1* 10/100/1000/2500 Mbps +
1*10/100/1000 Mbps
|
|
Controller
|
− Intel®i225V +i211AT Gigabit LAN
|
|
Connector
|
− 2 * RJ 45
|
|
Audio
|
|
CODEC
|
− HD Audio : Realtek ALC662 or ALC888
|
|
Channel
|
− Line‐Out, Line‐in, MIC
|
|
SATA
|
|
Max Data
Transfer Rate
|
− 4 * SATAIII (6.0Gb/s)
|
|
Rear I/O
|
|
VGA/HDMI
|
− 1
|
