BB-9PFLST
Transparent asynchronous RS-232 at 115.2 Kbps
Full or half-duplex
Range up to 4 km (2.5 mi)
TD, RD, RTS and CTS supported
EMI/RFI transient immunity to surges, spikes, ground loops
Port-powered, no external power required
Model 9PFLST allows any two pieces of RS-232 asynchronous serial equipment to communicate full-duplex over two multi-mode fibers. Typical distances up to 2.5 miles (4 km) are possible with no external power required. The 9PFLST supports both data signals at up to 115.2 kbps as well as the RTS/CTS handshake lines. This means the... More
相关产品
Inherent EMI/RFI immunity from surges, spikes, ground loopsExtend serial signals up to 4 km (2.5 mi) with multimode fiberPoint-to-point or multi-drop ring configurationConverts RS-232 to RS-422/485RS-
Data rates up to 115.2 kbps
4 km (2.5 mi) range
10 – 30 VDC input voltage
Wide operating temperature
2,000V, 2-way optical isolation
Modbus ASCII/RTU compatible
EMI / RFI protection
TD, RD and Power
Data rates up to 115.2 kbps
10 – 48 VDC input power range
Wide operating temperature
2,000V, 3-way optical isolation
Modbus ASCII/RTU compatible
EMI / RFI protection
UL Class 1/Division 2
Inverted fi
Dataratesupto115.2kbps15km(9mi)range10to48VDCpowerinputWideoperatingtemperature2000VoltsisolationModbus ASCII / RTU compatibleEMI / RFI protection
Data rates up to 115.2 kbps
15 km (9 mi) range
10 to 48 VDC power input
Wide operating temperature
2000 Volts isolation
Modbus ASCII / RTU compatible
EMI / RFI protection
ESD Protection - 8 kV Contact, 15 kV Air
Rugged Metal Case
Panel Mount with Available DIN Rail Adapters
Built-in Switchable Bias & Termination
UL Listed
ESD Protection - 8 kV Contact, 15 kV Air
Rugged Metal Case
Wide Operating Temperature
Panel Mount with Available DIN Rail Adapters
Built-in Switchable Bias & Termination
UL Listed
|
