Optically isolated digital current loop to serial conversionBaud rates up to 19.2 kbps
Transmit (T+ and T-) loop and Receive (R- and R-) loopEach current loop may be operated active or passiveDesigned for 20mA digital current loop
Model 232CL9R is a port-powered RS-232 to current loop converter. No external power required for passive loop installations, but a power supply is required to generate an active loop. Power supply sold separately.
Converts RS-232 to 20mA current loop
2000V optical isolation protection from transients
One Transmit current loop & Receive current loop
Current loops can be set to Active or Passive
-40 to 80°C wire
Converts serial data signals to multi- or single-mode fiber optic2kV, 3-way isolation on data ports and power circuits9.6 to 115.2 kbps data rate-40 to 85°C wide operatingtemperatureIP30 metal panel
Converts serial data signals to multi- or single-mode fiber optic2kV, 3-way isolation on data ports and power circuits9.6 to 115.2 kbps data rate-40 to 85°C wide operatingtemperatureIP30 metal panel
Convert 2 channels in each direction from 5V TTL (“Transistor Transistor Logic") to RS-232
Baud rates up to 115.2 kbps
Powered from RS-232 data/handshake lines - no power supply required
Converts 2 channels in each direction from 3.3V TTL (“Transistor Transistor Logic") to RS-232
Baud rates up to 115.2 kbps
Powered from RS-232 data/handshake lines - no power supply required
